AMX NX-2200 Hardware Reference Manual

Overview
7
Hardware Reference Guide - NX-Series NetLinx Integrated Controllers
NX-1200 Specifications (Cont.)
Rear Panel Components:
Digital I/O (Port 22): 1 6-pin 4-channel binary I/O port for contact closure with each input being capable of
voltage sensing. Input format is software selectable with interactive power sensing for
IR ports.
IR/Serial
(Ports 11-12):
2 2-pin IR/Serial control ports support high-frequency carriers of up to 1.142 MHz with
each output being capable of two electrical formats: IR or Serial.
2 IR/Serial data signals can be generated simultaneously.
IR ports support data mode (at limited baud rates and wiring distances).
RS-232/422/485
(Port 1):
1 10-pin RS-232/422/485 control ports using 3.5 mm mini-Phoenix (male) connectors
with XON/XOFF (transmit on/transmit off), CTS/RTS (clear to send/ready to send).
Supports 300-115,200 baud.
RS-232 (Port 2): 1 5-pin RS-232 control port using 3.5 mm mini-Phoenix (male) connectors with
XON/XOFF (transmit on/transmit off), CTS/RTS (clear to send/ready to send). Supports
300-115,200 baud.
AxLink Port: 1 4-pin 3.5 mm mini-Phoenix (male) connector that provides data and power to external
AxLink control devices. Green AxLink LED indicates the state of the AxLink port.
LAN 10/100 Port: 1 RJ-45 connector provides Ethernet communication. This is an Auto MDI/MDI-X
enabled port, which allows you to use either straight-through or crossover Ethernet
cables.
The LAN Port LEDs show communication activity, connection status, speeds, and mode
information:
• SPD (speed) - Yellow LED lights On when the connection speed is 100 Mbps and
turns Off when the speed is 10 Mbps.
• L/A (link/activity) - Green LED lights On when the Ethernet cables are connected and
terminated correctly, and blinks when receiving Ethernet data packets.
Power Connection: 2-pin 3.5 mm mini-Phoenix (male) connector with retention screws provides power to
the NX-1200.
General Specifications:
Operating
Environment:
• Operating Temperature: 32° F (0° C) to 122° F (50° C)
• Storage Temperature: 14° F (-10° C) to 140° F (60° C)
• Operating Humidity: 5% to 85% RH
• Heat Dissipation (On): 10.2 BTU/hr
Included
Accessories:
• 1 2-pin 3.5 mm mini-Phoenix (female) PWR connector
• 1 4-pin 3.5 mm mini-Phoenix (female) AxLink connector
• 1 6-pin 3.5 mm mini-Phoenix (female) I/O connector
• 1 10-pin 3.5mm mini-Phoenix (female) RS232/422/485 connector
• 1 5-pin 3.5mm mini-Phoenix (female) RS232 connector
• 1 CC-NIRC, IR Emitters (FG10-000-11)
Other AMX
Equipment:
• PSN6.5 - 6.5 A Power Supply (FG423-41)
• PSR4.4 - 4.4 A Power Supply (FG423-46)
• CC-USB-NI - USB Programming Cable (FG10-2105)
• CC-NIRC - IR Cables (FG10-000-11)
• CBL-ETH-FL, Ethernet Cat5e Flat Cable (FG1-2182-16)
• EXB-IRS4, ICSLan IR/S Interface, 4 IR/S and 4 Inputs (FG2100-23)
• EXB-COM2, ICSLan Serial Interface, 2 Ports (FG2100-22)
• EXB-REL8, ICSLan Relay Interface, 8 Channels (FG2100-20)
• EXB-I/O8, ICSLan Input/Output Interface, 8 Channels (FG2100-21)
• EXB-MP1, ICSLan Multi-Port, 1 COM, 1 IR/S, 2 I/O, 1 IR RX (FG2100-26)
