Analog Devices ADRV9029 User Manual

Preliminary Technical
Data
Rev. PrA | Page 25 of 82
Select Error Greater Than 3% 13% 10
The DPD recovery actions configured in the firmware on startup are listed in Table 9.
Table 9. Default Recovery Action Matrix
Metric
Recover Action if
Low Threshold is
Violated Once
Recover Action if
Low Threshold
Violation Persists
Recover Action if
High Threshold is
Violated Once
Recover Action if
High Threshold
Violation Persists
Mean TU Power (Pre-
DPD)
Abandon DPD LUT
Update
Take no action Take no action Take no action
Peak TU Power (Pre-
DPD)
Abandon DPD LUT
Update
Take no action Take no action Take no action
Mean Tx Power (Post-
DPD)
Abandon DPD LUT
Update
Take no action Take no action Take no action
Peak Tx Power (Post-
DPD)
Abandon DPD LUT
Update
Take no action Take no action Take no action
Mean ORx Power
(Post-DPD)
Abandon DPD LUT
Update
Take no action Take no action Take no action
Peak ORx power (Post-
DPD)
Abandon DPD LUT
Update
Take no action Take no action Take no action
Pre-DPD Capture Tx to
ORx EVM (Direct EVM)
Take no action Take no action Take no action Take no action
Post-DPD Capture Tx
to ORx EVM (Indirect
EVM)
Take no action Take no action Take no action Ta ke n o action
Indirect Error
Abandon DPD LUT
Update
Abandon DPD LUT
Update + Revert LUTs
to unity + Reset DPD
adaptation state + HW
reset DPD actuator
Take no action Take no action
Select Error
Abandon DPD LUT
Update
Abandon DPD LUT
Update + Revert LUTs
to unity + Reset DPD
adaptation state + HW
reset DPD actuator
Take no action Take no action
NOTE: The recovery actions follow a many-to-one mapping. Each of the four columns in the table indicate error conditions and
each error condition has a unique metrics-mask to which multiple fault condition metrics can be mapped by ‘OR’ing the metrics.
For example, in the matrix shown below, persistent error 0 looks for violation of lower thresholds from either indirect EVM,
mean TU power OR Peak Tx power, whereas persistent error1 looks for high threshold violations from indirect EVM only to
trigger a recovery action.
Error
Condition
Error0 - Fault
condition threshold0
violated once
Persistent0 – Fault
Condition Threshold0
violated persistenly
Error1 - Fault
condition threshold0
violated once
Persistent1 – Fault
Condition Threshold0
violated persistenly
