Analog Devices EVAL-AD2428WD1BZ User Guide

Page 2 of 6
System and Software Requirements
S. No
Software Component
Version
Comments
1.
A2B Software*
19.4.0*
Copy the DLL’s (A2B.DLL, A2BStack.DLL) into SigmaStudio
Installation Directory. Refer to the A2B Quick Start Guide for more
details (C:\Analog Devices\ADI_A2B_Software-Rel19.4.0\Docs)
2
SigmaStudio
4.6*
SigmaStudio 4.6 product page:
https://www.analog.com/en/design-center/evaluation-hardware-
and-software/software/ss_sigst_02.html#software-overview
*Please contact A2B SW team for latest updates.
Hardware Requirements
S. No
Name of Board
Type of Board/ Node
Quantity
1
EVAL-AD2428WD1BZ Rev. 1.1
Master/ Local Powered Slave (LPS)
2
2
Twisted Pair A2B Cable with DuraClik Connectors
-
1
3
12V Power Supply
-
2
4
USBi I2C Adapter
v1.5
1
5
Audio source (non-grounded)
e.g., PC/Mobile phone
2
6
Aux Cable
-
2
7
Audio Sink Devices
3.5mm Jack Headphones
2
8
SPDIF cable
4
9
SPDIF input source like say e.g., AP
1
10
SPDIF output sink e.g., AP
1
