MIXER
The audio mixer has five inputs. Each input has a level
control. Usually, patch VCO outputs into these jacks.
Filtering External Sounds
External sounds can be fed into the filter via the mixer.
Connect an auxiliary out from your external mixer, or line
level audio out from some device to the mixer.
Try feeding in drums, vocals, or other non-synth sounds!
NOISE / SUB
NOISE
There is an analogue white noise generator.
Use this for percussion, effects, wind, noise, breathe
sounds.
To use, patch into one of the mixer inputs.
SUB
There is a Sub-Oscillator.
This is a Square wave signal that is driven from VCO3 (it follows the same pitch as
VCO3) and is one octave lower.
Typically used to thicken up the bottom end. Good for devastating bass sounds!
To use, patch into one of the mixer inputs.
