Technical data of the spectrometers
SPECORD PLUS Edition 03/2013 17
3.2 General technical data of the SPECORD PLUS
Mass SPECORD 50 PLUS 26.0 kg
SPECORD 200 PLUS 26.6 kg
SPECORD 210 PLUS 26.9 kg
SPECORD 250 PLUS 27.5 kg
Footprint (W x D) approx. 900 x 690 mm
2
with PC
Dimensions (W x H x D) 590 x 290 x 690 mm
3
Mains voltage 85 264 V/AC
Frequency 50 60 Hz
Power consumption 200 VA
Fuses:
Mains fuses
2 x T 3.15 AH / 250V, type 19181 by Wickmann
Interference emission EN 55011 class B
EN 61000-3-2
EN 61000-3-3
EN 61326-1
Interference resistance EN 61326-1 (see also p. 13)
Protection type IP 20
Data connections 2 x RS-232 for accessories
1 x USB port for connecting an external PC
1 x RS232
PC software requirements:
WinASPECT PLUS
Windows XP Service Pack 2 operating system or better
32 bit version, USB 2.0
Overview 4 General technical data of the SPECORD PLUS
