AND GR Series - Unpacking and Installing Your Balance

9
3. Unpacking Your Balance
Unpack the balance carefully and keep the packing material if you want to transport the balance again in the
future. In the carton you should find this manual plus:
Note
Please confirm that the AC adapter type is correct for your local voltage and receptable type.
Please use the dedicated AC adapter specified for the balance.
If you use the wrong AD adapter, the balance and other equipment may not operate properly.
External
Contact Input
Serial Interface
(RS-232C)
Grounding Terminal
AC Adapter
Jack
Step
Card
Step
Card
Step Card
AC Adapter ID Lables
AC Adapter
Weighing
Chamber
Breeze
Break Ring
Dust Plate
Floor Plate
Door Control Lever
Door
Joint
Levelling
Foot
Bubble Spirit
Level
Display
Keys
A side door can be opened and closed
using the Door Control Lever when the
Door Joint is connected to a side door.
Weighing
Pan
