Remote Disconnected
This alarm is generated when the remote alarm (if connected) is disconnected. When a remote disconnected
alarm is generated the audible alarm in the control unit is activated, the alarm indicator on the control unit
flashes and the display window indicates that the remote has been disconnected as shown below. The self-test
relay in the base unit will also activate if the relays are armed.
R
e
m
o
t
e
D
i
s
c
o
n
n
e
c
t
e
d
M
o
r
e
A
l
a
r
m
s
The “More Alarms” message displayed on the fourth line will only appear if there is more than 1 alarm active. It
there is more than one alarm active then the up and down scroll keys are used to scroll through the other
alarm events present. To mute the audible alarm press the mute button on the front of the control unit.
User/Engineer Menu Functions
Accessing Menus
To access the user/engineer menus insert key into key-switch and turn then press the access menu key on the
front of the unit. Access to the system’s control menus is not possible if the key-switch is not in the active
position. While the base unit is granting control to the control unit the display window on the control unit will
change as shown below
P
l
e
a
s
e
W
a
i
t
C
o
n
n
e
c
t
i
n
g
Once the base unit has passed control to the display it unit will display page one of the user menus as shown
below
