FL 128 Multizone System 15.01.2021 23
Next Page (Engineers Menu Page 1)
Selects Engineers menu page 2. To select this option, move the ‘>’ character on the far left using the up and
down scroll keys until it is opposite “Next Page” on the display then press the enter key. Once this item has
been selected the display will change to engineer’s menu page 2 as shown below
>
P
r
e
v
i
o
u
s
P
a
g
e
S
e
t
Z
o
n
e
M
e
s
s
a
g
e
S
e
t
L
e
a
k
T
h
r
e
s
h
o
l
d
The menu system operates in the same manner to that described above. The function of each of engineer’s
menu page 2 option is detailed below.
Previous Page (Engineers Menu Page 2)
The option returns the engineer to engineer’s menu page 1. To select this option, move the ‘>’ character on the
far left using the up and down scroll keys until it is opposite “Previous Page” on the display then press the enter
key.
Set Zone Message
This option allow customisation of the message displayed on the third line of the display when an open circuit,
short circuit or leak alarm is activated on a per zone bases. To select this option, move the ‘>’ character on the
far left of the display using the up and down scroll keys until it is opposite “Set Zone Message” then press the
enter key. Once this option has been selected the display will change to that shown below.
Z
o
n
e
0
0
1
M
e
s
s
a
g
e
The number of the zone whose message is to be changed is now selected using the up and down scroll keys.
Once the zone number required is displayed pressing the enter key to allows the zone message to be edit. The
current zone message that will appear on the third line of the display with a flashing cursor on the far left,
which highlights the first character that can be changed, this is shown below.
