Read Zone Resist
Allows the engineer to take resistance readings in k ohms of the loop resistance of each zone connected to the
system. To select this option, move the ‘>’ character on the far left until it is opposite “Read Zone Resist” on the
display then press the enter key. Once the enter key is pressed the display will change to that shown below.
E
n
t
e
r
Z
o
n
e
N
u
m
.
=
0
0
1
The up and down scroll keys are now used to scroll through the zone numbers once the zone number required
is displayed pressing the enter key causes the system to take a resistance reading form that zone. The user
display window will then show the resistance reading for that zone as shown below.
E
n
t
e
r
Z
o
n
e
N
u
m
.
=
0
0
1
R
e
s
i
s
t
a
n
c
e
=
1
0
0
8
K
To clear this display and return to page 1 of the engineer’s menus press the enter key.
