Andel Floodline 32 - Appendix I (OVERFLOW;TUNDISH Connection Details)

FL 128 Multizone System 15.01.2021 58
Appendix I (OVERFLOW/TUNDISH Connection Details)
Date
09/11/96
Drawn By M.J.Booth
Sheet
1
of
Rev
1
ANDEL LIMITED
Bridge Street Mills
Slaithwaite, Huddersfield
1
END OF LINE (EOL) RESISTOR 1 MEG OHM
SINGLE TUNDISH SENSOR CONNECTED
INTO ZONE 1 OF INTPUT TERMINALS
A STRING OF TUNDISH SENSORS CONNECTED
INTO ZONE 1 OF INTPUT TERMINALS
TUNDISH SENSOR CONNECTION DETAILS
OR EOL
IN
OUT
OUT
IN
OR EOL
OUT
IN
OR EOL
OUT
IN
OR EOL
ZONE INPUT CONNECTIONS
C
1
2
3
4
C
5
6
7
8
C
ZONE INPUT CONNECTIONS
C
1
2
3
4
C
5
6
7
8
C
CONNECTIONS TO LEAK DETECTION MODULE
CONNECTIONS TO LEAK DETECTION MODULE
