Andel Floodline 32 - Short Circuit Alarm; Open Circuit Alarm

FL 128 Multizone System 15.01.2021 13
Short Circuit Alarm
A short circuit alarm is generated on a per zone bases when the loop resistance of the zone falls below 1k ohm.
When a short circuit alarm is generated the audible alarm in the control unit is activated, the alarm indicator on
the control unit flashes and the display window indicates the zone in which the alarm was activated as shown
below. The system fault relay in the base unit will also activate if the relays are armed.
S
h
o
r
t
C
i
r
c
u
i
t
Z
o
n
e
1
6
R
O
O
M
1
0
M
o
r
e
A
l
a
r
m
s
The “More Alarms” message displayed on the fourth line will only appear if there is more than 1 alarm active. It
there is more than one alarm active then the up and down scroll keys are used to scroll through the other
alarm events present. To mute the audible alarm press the mute button on the front on the control unit.
Open Circuit Alarm
An open circuit alarm is generated on a per zone bases when the loop resistance of the zone rises above 4M
ohms. When an open circuit alarm is generated the audible alarm in the control unit is activated, the alarm
indicator on the control unit flashes and the display window indicates the zone in which the alarm was
activated as shown below. The system fault relay in the base unit will also activate if the relays are armed.
O
p
e
n
C
i
r
c
u
i
t
Z
o
n
e
1
6
R
O
O
M
1
0
M
o
r
e
A
l
a
r
m
s
The “More Alarms” message displayed on the fourth line will only appear if there is more than 1 alarm active. It
there is more than one alarm active then the up and down scroll keys are used to scroll through the other
alarm events present. To mute the audible alarm, press the mute button on the front of the control unit.
