2 Introduction
ID No: 7164491 Page 15
8. Login to the unit and follow the installation wizard option for easy
installation.
a. Optimize the donor antenna performance.
b. To select the channels for enhancement, choose between the
“Measurement Assisted Channel Assignment” or “Unassisted
Channel Assignment” from the Setup Wizard page.
c. Enter the desired output power in the downlink.
d. Enter the relative uplink gain and click the “Program” button.
e. Select the “Connectivity and Upload” button, to setup the modem (if
applicable) and to enter data in the other user fields.
f. Select the “Technician Setup” button, to change additional system
settings, e.g. ICE, frequency hopping, EDGE.
The “Technician Setup” is also accessible from the home page.
9. The Node G setup is complete.
10. Open the “Save Configuration to Laptop” menu for record keeping
purposes.
11. Unplug the computer, close the Node and tighten all screws.
) Note: To do a power cycle, disconnect the battery pack by pushing the
battery disconnect button on the battery charge module.
