Common Product Information
Document No. 992012. Issue 16 – 12.01.21
Page 25
Depress the brake pedal to brake all four
castors.
Depress the steering pedal to engage the
5
th
wheel steering function.
Pump the raise and lower pedal to raise
the patient platform, lift the raise and
lower pedal to lower the patient platform.
Lift the side rail release lever to lower the
side rail.
Pull up on the backrest actuation lever to
adjust the backrest angle.
Pull up on the Trendelenburg actuation
lever to adjust the patient platform angle.
The IV pole must be fully inserted into the
mounting socket to be locked into the
vertical position. The maximum weight
per hook is 3kg (6.6lbs) and the safe
working load for the IV pole is 6kg
(13.2lbs).
Incompatible mattress can create a hazard.
Label to indicate that the trolley must be
fitted with an 800mm (31.5”) wide
mattress.
