Anglecare AC327 - Top Status Bar

TOP STATUS BAR
1
2
3
4
5
6
7
8
9
10 11 12
14
15
13
16
17
18 19 20
1
Sensor Pad movement detection
is activated
2
Sensor Pad alert
3
Sensor Pad is connecting
4
Sensor Pad lost link
5
Sensor Pad movement detection
is OFF
6
Sensor Pad is paused
7
Sensor Pad is low battery
8
Sensor Pad has never been paired
9
Nursery Unit selected and
broadcasting sound
10
“TIC” function is activated
11
VOX Sound is activated
12
VOX Video is activated
13
Temperature alert is
activated
14
Temperature alert: too hot
15
Temperature alert: too cold
16
Night vision is activated
17
Second Sensor Pad is low
battery - only shown if you
have 2 Sensor Pads paired
18
Volume level indicators
19
Reception quality indicators
20
Parent Unit battery level
indicators
MAIN MENU
ON ON 42 3
1 2 3 4 5 6 7
1
Movement Sensor Pad Activation:
ON: e Parent & Nursery Units will alarm if there
is no movement after 20 seconds.
PAUSE: Allows you to pause the Sensor Pad if
you remove baby from the cot, e.g. for feeding or
comforting.
• e Pause icon in the status bar will flash.
• e Nursery Unit Power indicator will slowly blink.
Ensure to un-pause the Sensor Pad before putting
baby in the cot (Turn movement detection ON).
OFF: When your baby gets older, allows you to turn
movement detection OFF and use your monitor for
video only.
2
Tic Activation:
If movement detection is activated, allows you
to hear a Tic sound every 5 seconds. In the event
you have two Sensor Pads connected, the Tic
indication will flash green for Sensor Pad 1 and
blue for Sensor Pad 2.
3
VOX Sound Set-Up: VOX Sound means that it
will transmit sounds only when it detects them,
based on the setting of the sensitivity level (level
4 being the most sensitive). To save power, after
10 seconds, the sound transmission will stop if
no sound is detected. VOX Sound OFF means the
sound monitoring is continuously transmitting,
picking up all sounds.
4
VOX Video Set-Up: VOX Video means that when
Parent Unit is in sleep mode (black screen) the
screen will turn ON only when it detects sounds,
based on the setting of the sensitivity level (level
4 being the most sensitive). To save power, after
the set time, the sleep mode will be activated.
Video VOX OFF means the Parent Unit screen
will not turn ON if the Nursery Unit is picking up
sounds.
5
Screen Brightness
6
Temperature Settings
7
General Settings
