PARTS
FRONT VIEW
TOP VIEW
REAR VIEW
BOTTOM VIEW
6. SET Button
4. Tune up/ Next Button
7. Volume down/ Alarm 1 Button
3. Tune down/ Previous Button
Buzzer ringing of Alarm 2
Clock indicator
FM frequency indicator
FM Station searching
indicator
Radio ringing of Alarm 2
Buzzer ringing of Alarm 1
Radio ringing of Alarm 1
1 2 3 4 5 6
7 8 9
10 11 12
13
8. SNOOZE/ Sleep/ Dimmer Button
9. Volume up/ Alarm 2 Button
11. FM Antenna
10. DC IN Jack
13. Backup Battery Compartment
12. Speaker
1. Power Button
2. AM/FM Button
5. MEMORY Button
FM AN T
DC IN 5V
12H System indicator
(it will light up in PM time)
