Initial Condition Setting 2.4.2.
The initial conditions must be set before measurement.
An example of the following settings is shown below.
Component
Carrier
Channel
FDD
TDD
Channel
Bandwidth
PCC
UL Channel
18300 (Band1)
38000 (Band38)
10 MHz
DL Channel
300 (Band1)
38000 (Band38)
SCC–1
DL Channel
2525 (Band5)
39150 (Band40)
20 MHz
SCC–2
DL Channel
4450 (Band10)
39500 (Band40)
10 MHz
SCC–2
DL Channel
444 (Band10)
38144 (Band40)
20 MHz
2.4.2.1. MT8821C
2.4.2.1.1. Setting Example 1 (FDD)
1. Execute PRESET to set the default parameters.
2. Execute CHCODING RMC_DL_CA_PCC to set Common Parameter – Channel Coding to RMC (DL CA).
3. Execute DLSCC 3 to set Call Processing Parameter – Number of DL SCC to 3.
4. Execute CALLPROC ON to set Common Parameter – Call Processing to On.
5. Execute DLCHAN 300 to set Common Parameter – UL Channel and DL Channel to 18300 and 300,
respectively.
6. Execute DLCHAN_SCC1 2525 to set Common Parameter – SCC-1 – DL Channel to 2525.
7. Execute DLCHAN_SCC2 4450 to set Common Parameter – SCC-2 – DL Channel to 4450.
8. Execute DLCHAN_SCC3 444 to set Common Parameter – SCC-3 – DL Channel to 444.
9. Execute BANDWIDTH 10MHZ to set Common Parameter - Channel Bandwidth to 10 MHz.
10. Execute BANDWIDTH_SCC1 20MHZ to set Common Parameter – SCC-1 – Channel Bandwidth to 20 MHz.
11. Execute BANDWIDTH_SCC2 10MHZ to set Common Parameter – SCC-2 – Channel Bandwidth to 10 MHz.
12. Execute BANDWIDTH_SCC3 20MHZ to set Common Parameter – SCC-3 – Channel Bandwidth to 20 MHz.
2.4.2.1.2. Setting Example 2 (TDD)
The procedure described in Chapter 2.3.3.2.1 is used, but substituting the following steps to set Uplink/Downlink
Configuration and Special Subframe Configuration.
5. Execute DLCHAN 38000 to set Common Parameter – DL Channel and UL Channel to 38000
simultaneously.
6. Execute DLCHAN_SCC1 39150 to set Common Parameter – SCC-1 – DL Channel to 39150.
7. Execute DLCHAN_SCC2 39500 to set Common Parameter – SCC-2 – DL Channel to 39500.
8. Execute DLCHAN_SCC3 38144 to set Common Parameter – SCC-3 – DL Channel to 38144.
13. Execute TDDULDLCONF 1 to set Common Parameter – TDD Uplink/Downlink Configuration to 1.
14. Execute TDDSSFCONF 4 to set Common Parameter – TDD Special Subframe Configuration to 4.
NOTE 1: Set the same value as Uplink/Downlink Configuration in PCC and SCC.
NOTE 2: Set the same value as Special Subframe Configuration in PCC and SCC.
NOTE 3: The differential UL/DL Configuration on each CC is not supported.
