LTE Measurement Software 1.
Specifications 1.1.
MT8820C 1.1.1.
1.1.1.1. MX882012C/13C (Call Processing)
Table 1.1.1.1-1 LTE Measurement Software Specifications (MX882012C/13C)
Measurement Item
Specifications
Electrical
Typical values (typ.) are only for reference and are not guaranteed.
Modulation Analysis
Frequency 400 to 2700 MHz
3400 to 3800 MHz
(Can be used when installing MT8820C-018 option)
Input level –40 to +35 dBm (Main1)
Carrier frequency
accuracy ±(Set frequency × Reference oscillator accuracy
+15 Hz)
Modulation accuracy
Residual vector error ≤2.5% (400 to 2700 MHz)
(3400 to 3800 MHz, 18° to 28°C)
(When measurement count is 20)
≤3.0% (3400 to 3800 MHz, 20 measurements)
In-band Emissions ≤–40 dB
(≥–10 dBm, Allocated RB≤18)
Measurement object PUSCH, PRACH, PUCCH
Amplitude
Measurement
Frequency 400 to 2700 MHz
3400 to 3800 MHz
(Can be used when installing MT8820C-018 option)
Input level –60 to +35 dBm (Main1)
Measurement accuracy ±0.5 dB (–20 to +35 dBm),
typ. ±0.3 dB (–20 to +35 dBm)
±0.7 dB (–50 to –20 dBm)
±0.9 dB (–60 to –50 dBm)
400 to 2700 MHz, 10° to 40°C after calibration
±0.5 dB (–20 to +35 dBm, 18° to 28°C),
typ. ±0.3 dB (–20 to +35 dBm, 18° to 28°C),
±0.7 dB (–50 to –20 dBm),
±0.9 dB (–60 to –50 dBm),
3400 to 3800 MHz, 10° to 40°C after calibration
Linearity ±0.2 dB (–40 to 0 dB, ≥–50 dBm)
±0.4 dB (–40 to 0 dB, ≥–60 dBm)
400 to 2700 MHz
±0.2 dB (–40 to 0 dB, ≥–50 dBm, 18° to 28°C),
±0.3 dB (–40 to 0 dB, ≥–50 dBm)
±0.4 dB (–40 to 0 dB, ≥–60 dBm)
3400 to 3800 MHz, 10° to 40°C after calibration
Relative measurement error
<2 dB
typ. ±0.10 dB (–40 to 0 dB, ≥–50 dBm)
