Test Parameters Supporting 3GPP Test Items 3.8.
Table 3.8-1 to Table 3.8-5 show the relationship between 3GPP TS36.521-1 defined test items and test parameters.
Set test parameters matching each test item to test.
No. in Table 3.8-1 to Table 3.8-5 corresponds to No. in Table 3.9-1 to Table 3.9-6.
Table 3.8-1: 3GPP Test Items and Test Parameters (1/5)
3GPP Test Item
No.
Test Parameter
6.2.2 UE Maximum Output Power
4
TX1 - Max. Power (QPSK/1RB)
5
TX1 - Max. Power (QPSK/PartialRB)
6.2.2_1 Maximum Output Power for HPUE
4
TX1 - Max. Power (QPSK/1RB)
5
TX1 - Max. Power (QPSK/PartialRB)
6.2.2A.1 UE Maximum Output Power for CA
(intra-band contiguous DL CA and UL CA)
4
TX1 - Max. Power (QPSK/1RB)
5
TX1 - Max. Power (QPSK/PartialRB)
6.2.3 Maximum Power Reduction (MPR)
6
TX1 - Max. Power (QPSK/FullRB)
7
TX1 - Max. Power (16QAM/PartialRB)
8
TX1 - Max. Power (16QAM/FullRB)
6.2.3_1 Maximum Power Reduction (MPR) for HPUE
6
TX1 - Max. Power (QPSK/FullRB)
7
TX1 - Max. Power (16QAM/PartialRB)
8
TX1 - Max. Power (16QAM/FullRB)
6.2.3A.1 Maximum Power Reduction (MPR) for CA
(intra-band contiguous DL CA and UL CA)
6
TX1 - Max. Power (QPSK/FullRB)
7
TX1 - Max. Power (16QAM/PartialRB)
8
TX1 - Max. Power (16QAM/FullRB)
6.2.4 Additional Maximum Power Reduction (A-MPR)
6
TX1 - Max. Power (QPSK/FullRB)
6.2.4_1 Additional Maximum Power Reduction
(A-MPR) for HPUE
6
TX1 - Max. Power (QPSK/FullRB)
6.2.4A.1 Additional Maximum Power Reduction (A-MPR)
for CA (intra-band contiguous DL CA and UL CA)
6
TX1 - Max. Power (QPSK/FullRB)
6.2.5 Configured UE Transmitted Output Power
17
TX2 - Configured Power (Test Point 1)
18
TX2 - Configured Power (Test Point 2)
19
TX2 - Configured Power (Test Point 3)
6.2.5_1 Configured UE Transmitted Output Power for
HPUE
17
TX2 - Configured Power (Test Point 1)
18
TX2 - Configured Power (Test Point 2)
19
TX2 - Configured Power (Test Point 3)
6.2.5A.1 Configured UE Transmitted Output Power for CA
(intra-band contiguous DL CA and UL CA)
17
TX2 - Configured Power (Test Point 1)
18
TX2 - Configured Power (Test Point 2)
19
TX2 - Configured Power (Test Point 3)
6.3.2 Minimum Output Power
9
TX1 - Min. Power
6.3.2A.1 Minimum Output Power for CA
(intra-band contiguous DL CA and UL CA)
9
TX1 - Min. Power
6.3.4.1 General ON/OFF time mask
16
TX2 - General Time Mask
6.3.4A.1.1 General ON/OFF Time Mask for CA
(intra-band contiguous DL CA and UL CA)
16
TX2 - General Time Mask
6.3.4.2.1 PRACH time mask
1
Idle/Call - PRACH Time Mask
6.3.4.2.2 SRS time mask
43
TX3 - SRS Time Mask
