Chapter 4 OTDR Commands
4-32
4.6.4 DISPlay:ZOOM:HORIzontal Command
Syntax: DISPlay:ZOOM:HORIzontal<wsp><level>
Parameters: <level> Zoom level
Numeric format
Range: 0 – (6 - 16) Depends on current distance range
0 – Full zoom in, (6 – 16) – Full Zoom out
Note:
The maximum value for each distance is as follows.
0.5 km : 6
1 km : 7
2.5 km : 8
5 km : 9
10 km : 10
25 km : 11
50 km : 12
100 km : 13
200 km : 14
300 km : 16
Description: Set Horizontal display zoom to specified level
Example: disp:zoom:hori 2
Response: None
Errors: (–224, "std_illegalValue, Invalid Parameter Value")
4.6.5 DISPlay:ZOOM:HORIzontal? Command
Syntax: DISPlay:ZOOM:HORIzontal?
Parameters: None
Description: Get Horizontal display zoom level
Example: disp:zoom:hori? --- 5<END>
Response: Horizontal zoom level as numeric value.
Errors: None
