A-1 Test Records for Spectrum Analyzer Verification
A-2 PN: 10580-00253 Rev. J S3xxE MM
A-1 Test Records for Spectrum Analyzer Verification
S3____E Firmware Rev: ______________ Operator: ____________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-1. Spectrum Analyzer Frequency Accuracy
Frequency Measured Value Deviation Specification
1 GHz GHz kHz ± 1.5 kHz (± 1.5 ppm)
3.9 GHz GHz kHz ± 5.85 kHz (± 1.5 ppm)
(S362E only) 5.9 GHz GHz kHz ± 8.85 kHz (± 1.5 ppm)
Table A-2. Spectrum Analyzer SSB Phase Noise Verification
Frequency Measured Value Calculated Value Specification
10 kHz dBc/Hz dBc/Hz ≤ –100 dBc/Hz
100 kHz dBc/Hz dBc/Hz ≤ –105 dBc/Hz
1 MHz dBc/Hz dBc/Hz ≤ –115 dBc/Hz
Table A-3. Spectrum Analyzer Spurious Response (Second Harmonic Distortion)
Frequency Measured Value 2nd Harmonic Distortion Specification
50.1 MHz
100.2 MHz dBc ≤ –56 dBc
