A-1 Test Records for Spectrum Analyzer Verification
A-4 PN: 10580-00253 Rev. J S3xxE MM
S3____E Firmware Rev: ______________ Operator: _________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-6. Spectrum Analyzer 50 MHz Absolute Amplitude Accuracy
Input Power Level Reference Level Input Atten. Level Measured Reading Specification
0 dBm 10 dBm 30 dB dBm ± 1.25 dB
–4 dBm 10 dBm 30 dB dBm ± 1.25 dB
–10 dBm 0 dBm 20 dB dBm ± 1.25 dB
–14 dBm 0 dBm 20 dB dBm ± 1.25 dB
–20 dBm –10 dBm 10 dB dBm ± 1.25 dB
–24 dBm –10 dBm 10 dB dBm ± 1.25 dB
–30 dBm –20 dBm 0 dB dBm ± 1.25 dB
–34 dBm –20 dBm 0 dB dBm ± 1.25 dB
–40 dBm –30 dBm 0 dB dBm ± 1.25 dB
–44 dBm –30 dBm 0 dB dBm ± 1.25 dB
–50 dBm –40 dBm 0 dB dBm ± 1.25 dB
Turn Pre-Amp On (for the below measurement)
–44 dBm –40 dBm 10 dB dBm ± 1.25 dB
–50 dBm –45 dBm 5 dB dBm ± 1.25 dB
Table A-7. Spectrum Analyzer Absolute Amplitude Accuracy Across Frequency Setup Table
Frequency
Required Sensor B
reading for –2 dBm @
Attenuator output
Required Sensor B
reading for –30 dBm @
Attenuator output
Required Sensor B
reading for –50 dBm @
Attenuator output
10.1 MHz dBm dBm dBm
50 MHz dBm dBm dBm
100 MHz dBm dBm dBm
500 MHz dBm dBm dBm
1000 MHz dBm dBm dBm
2000 MHz dBm dBm dBm
3000 MHz dBm dBm dBm
3990 MHz dBm dBm dBm
