A-3 Test Records for Options Verification
A-14 PN: 10580-00253 Rev. J S3xxE MM
S3____E Firmware Rev: ______________ Operator: _________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-18. Option 29, Characterization Chart for Power Meter Verification
Test Power Level @ 50 MHz Required Sensor B Reading
0dBm dBm
–50 dBm dBm
Test Power Level @ 3900 MHz
(S332E only) Required Sensor B Reading
0dBm dBm
–50 dBm dBm
Test Power Level @ 5900 MHz
(S362E only) Required Sensor B Reading
0dBm dBm
–50 dBm dBm
Table A-19. Option 29, Internal Power Meter Accuracy Verification
Frequency Input Power Measured Values Specification
50 MHz 0 dBm dBm ± 1.25 dB
–50 dBm dBm ± 1.25 dB
3.9 GHz
(S332E only)
0 dBm dBm ± 1.25 dB
–50 dBm dBm ± 1.25 dB
5.9 GHz
(S362E only)
0 dBm dBm ± 1.50 dB
–50 dBm dBm ± 1.50 dB
Table A-20. Option 31, GPS Receiver Frequency Accuracy Verification
Frequency Measured Value Error Specification
Spectrum Analyzer Frequency Accuracy with GPS High Frequency Accuracy (S332E or S362E only)
4.0 GHz GHz Hz ± 350 Hz (± 50 ppb)
Spectrum Analyzer Frequency Accuracy with Internal High Frequency Accuracy (S332E or S362E only)
4.0GHz GHz Hz ± 1.2kHz (± 0.3ppm)
