External Detectors
The following Anritsu detectors can be used with the Site Master S331D when equipped
with Option 5, Power Monitor.
Model
Frequency
Range
Impedance Return Loss
Input
Conn.
Frequency Response
5400-71N50 0.001 to 3 GHz 50W 26 dB N(m)
±0.2 dB, <1 GHz
±0.3 dB, <3 GHz
5400-71N75 0.001 to 3 GHz 75W
26 dB, <2 GHz
20 dB, <3 GHz
N(m)
±0.2 dB, <1 GHz
±0.5 dB, <3 GHz
560-7N50B 0.01 to 20 GHz 50W
15 dB, <0.04 GHz
22 dB, <8.00 GHz
17 dB, <18.0 GHz
14 dB, <20.0 GHz
N(m)
±0.5 dB, <18 GHz
±1.25 dB, <20 GHz
560-7S50B 0.01 to 20 GHz 50W
15 dB, <0.04 GHz
22 dB, <8.00 GHz
17 dB, <18.0 GHz
14 dB, <20.0 GHz
WSMA
(m)
±0.5 dB, <18 GHz
±2.0 dB, <20 GHz
560-7K50 0.01 to 40 GHz 50W
12 dB, <0.04 GHz
22 dB, <8.00 GHz
17 dB, <18.0 GHz
15 dB, <26.5 GHz
14 dB, <32.0 GHz
13 dB, <40.0 GHz
K(m)
±0.5 dB, <18 GHz
±1.25 dB, <26.5 GHz
±2.2 dB, <32 GHz
±2.5 dB, <40 GHz
560-7VA50 0.01 to 50 GHz 50W
12 dB, <0.04 GHz
19 dB, <20.0 GHz
15 dB, <40.0 GHz
10 dB, <50.0 GHz
V(m)
±0.8 dB, <20 GHz
±2.5 dB, <40 GHz
±3.0 dB, <50 GHz
