Function Hard Keys
MODE Opens the mode selection box (below). Use the Up/Down arrow key to select a
mode. Press the
ENTER key to implement.
NOTE: Available mode selections will vary according to model number and
options installed.
FREQ/DIST Displays the Frequency or Distance to Fault soft key menus depending on the
measurement mode (see page 2-11).
AMPLITUDE Displays the amplitude soft key menu for the current operating mode (see page
2-13).
MEAS/DISP Displays the measurement and display soft key menus for the current operating
mode (see page 2-14).
Chapter 2 Functions and Operations
2-5
o Measurement Mode
Freq - SWR
Return Loss
Cable Loss - One Port
DTF - SWR
Return Loss
Power Monitor (External Detector)
High Accuracy Power Meter
Figure 2-4. Mode Selection Box
