Chapter 1 General Information
Power Monitor (Option 5, with external detector)
Measurement Range: –50 dBm to +16 dBm (10 nW to 40 mW)
Offset Range: 0 dB to +60 dB
Display Range: –80 dBm to 80 dBm
Resolution: 0.1 dB, 0.1 xW
Measurement Accuracy: ±1 dB maximum for >–40 dBm and <18 GHz using 560-7N50B
(see uncertainty curves)
High Accuracy Power Meter (Option 19)
Compatible Sensors: PSN50 and MA24104A
PSN50 High Accuracy Power Sensor:
Frequency Range: 50 MHz to 6 GHz
Measurement Range: –30 dBm to +20 dBm
Sensor Linearity: ± 0.13 dB
Input Connector: Type N, male, 50W
Refer to the PSN50 Technical Data Sheet, PN: 11410-00423, for complete specifications.
MA24104A Inline High Power Sensor:
Frequency Range: 600 MHz to 4 GHz
Measurement Range: +3 dBm to +51.76 dBm (2 mW to 150 W)
Sensor Linearity: ± 0.13 dB
Input Connector: Type N, female, 50W
Output Connector: Type N, female, 50W
Refer to the MA24104A Technical Data Sheet, PN: 11410-00483, for complete specifications.
Table 1-1. Performance Specifications (2 of 3)
