Communication Port Setting
The Handheld Software Tools communicates with the instrument through a standard serial
COM port on the PC. Set the baud rate of the COM port to 115200.
Step1.
Select Start, Programs and select Software Tools.
Step2.
When the program has loaded, select Settings, Communication.
Step3. Select the appropriate PC COM port and Transfer Baud Rate for your system,
and click OK. (For the optional USB Adapter Cable (551-1691) set the COM
port to COM 4, and the baud rate to 38400.)
Chapter 7 Handheld Software Tools
7-3
Figure 7-1. Communication Setting Dialog Box
