2. Place the window insert in the window
opening.
FIG. 10
3. Cut the non self-adhesive foam rubber seal
(H) to a suitable length for the width of the
window. Place the seal between the glass
and the jamb to prevent draughts.
FIG. 11
4. If necessary t the safety fastener with the 2
screws as shown in the diagram.
FIG. 12
5. Place the window insert adapter in the hole
in the window insert.
FIG. 13
Mounting in horizontal sliding
window
1. Cut the self-adhesive foam rubber seals
(F) and (G) to a suitable length and fasten
them on the jamb and window frame as
shown in the diagram.
FIG. 14
2. Place the window insert in the window
opening.
FIG. 15
3. Cut the non self-adhesive foam rubber seal
H to a suitable length for the height of the
window. Place the seal between the glass
and the jamb to prevent air and insects
coming into the room.
FIG. 16
4. If necessary t the safety fastener with the 2
screws as shown in the diagram.
FIG. 17
5. Place the window insert adapter in the hole
in the window insert.
FIG. 18
WALL MOUNTING
1. Make a hole with a diameter of 125 mm
in the wall or for the wall outlet adapter B.
The hold must be placed from 30 – 120 cm
over the oor.
FIG. 19
2. Fasten the wall outlet adapter (B) to the
wall with 4 screws and plugs.
3. Connect the outlet hose to the wall outlet
adapter.
4. For best functionality do not stretch or bend
the hose.
FIG. 20
NOTE:
• Fit the adapter cover over the hole when
the appliance is not in use.
• Check that there are no obstacles within
50 cm of the air outlet, otherwise the
outlet system will not work properly.
USE
SETTING THE FUNCTION MODES
COOL mode
1. Continue pressing the MODE button until
the COOL status light goes on.
2. Set the required room temperature (set
point temperature) with the + and -
buttons. The temperature can be set from
17 to 30°C or from 62 to 88°F.
3. Press the FAN SPEED button on the remote
control to set the fan speed.
DRY mode (dehumidication)
1. Continue pressing the MODE button until
the DRY status light goes on. In this mode
it is not possible to adjust the temperature
or fan speed. The fan motor runs at low
speed.
