Antec SKELETON - Default Chapter; Table of Contents

Table of Contents
Introduction
1.1 Case Specifications………………...……………......…………… 2
1.2 Diagram……………………………………………....…......……… 2
1.3 How to Carry the Skeleton…………………………….…......…. 3
Hardware Installation Guide
2.1 Removing/Replacing the Component Tray…………......…….. 3
2.2 Removing the Motherboard Tray …………………......….……. 4
2.3 Motherboard Installation……………………………….......……. 4
2.4 Removing the Frame Side Screen Panels…………………..….. 5
2.5 Power Supply Installation…………………………….…......…... 5
2.6 5.25” Quick Release Device Installation……………….………. 6
2.7 3.5” Quick Release Device Installation…………………………. 6
2.8 3.5” Device Frame-Mounted Installation………….…………… 7
2.9 PCI Card Mounting Bar Installation……….................……….. 7
Connecting the Front I/O Ports
3.1 USB 2.0 Ports……………………………...……........…………… 8
3.2 eSATA Port………………………………...……......…..………… 8
3.3 IEEE 1394 Port…………………………….......………….…........ 8
3.4 AC’97 / HD Audio Ports......……………….................………. 9
3.5 Power Switch / Reset Switch /
Hard Disk Drive LED Connectors.........………….……………… 9
Cooling System
4.1 The Super Big Boy 250mm Multi-LED Fan.…….........……….. 10
4.2 92 mm Hard Drive Fan……………….....……………..........….. 10
4.3 Removing the 92mm Hard Drive Fan…….....………………….. 11
