In the example shown, the trigger activates while Main or Zone 2 power is turned on.
Trigger outputs can also be set to activate according to any combination of inputs
instead of Power.
If triggers are to be controlled through IP or RS-232, change “Menu” to “RS-232/IP”.
TCP PORT
Change this only if there is a conflict with another application that uses 14999. Available
settings are 1025 to 49150.
REAR AND FRONT IR
This allows you to disable each of the receiver’s infra-red inputs, which can be useful
when the receiver is connected to an IR repeater and is receiving too many signals.
Note that the moment that you disable the front IR input, you will not be able to control
the receiver the traditional way from the remote control – re-enable the IR input using
the front panel buttons. If your remote control appears to not be working and you have
checked the batteries, check this menu next before contacting technical support.
TX STATUS
When enabled, all commands, status changes, and control information are reported
through the Ethernet and RS-232 connections.
CONTROL4 ID TX
If setting up a Control4 system, press Select to transmit the SDDP discovery signal.
