General description of the lamp.
a Lamp handle.
b Rotary end.
c Optical conductor (10 mm).
d Anti-reflective cone.
e Power cord.
f Control panel.
• The curing light can be used in different configurations (wand,
gun or any intermediate position) as it is more convenient for
the user.
• The curing light is delivered in its original packing which
should be kept for future shipment.
Description of the control panel.
A LCD screen to display the set work cycle and other information.
B “START/STOP” raised button for activation/interruption of the work
cycle.
Pressing the button activates the light beam emission according to
the selected cycle.
If desired, the light can be turned off before the end of the work
cycle by pressing the “START/STOP” button again.
C “MODE” button for work cycle selection.
This button is used to select the cycle to be run. The selection of
work cycles is cyclical.
The cycle can be selected and the button is operative only when
the curing light is not emitting any light. If the button is
accidentally pressed while light is being emitted, nothing will
happen.
Description of pre-set work cycles.
1 STANDARD cycle (constant power):
Emission of 1000 mW/sq.cm for 20 seconds (this cycle is set as
default at the time of sale).
2 FAST cycle (constant power):
Emission of 1400 mW/sq.cm for 15 seconds.
3 STRONG cycle (constant power):
Emission of 2200 mW/sq.cm for 20 seconds.
4 BONDING cycle (ramp):
Ramp cycle with emission of 600 mW/sq.cm for 5 seconds, ramp
from 600 to 1100 mW/sq.cm for 5 seconds and 1100 mW/sq.cm
for 5 seconds for a total of 15 seconds.
5 RAPID RESTORATION cycle (ramp):
Ramp cycle with emission of 600 mW/sq.cm for 5 seconds, ramp
from 600 to 2400 mW/sq.cm for 5 seconds and 2400 mW/sq.cm
for 5 seconds for a total of 15 seconds.
6 LONG RESTORATION cycle (ramp):
Ramp cycle with emission of 600 mW/sq.cm for 5 seconds, ramp
from 600 to 2000 mW/sq.cm for 5 seconds and 2000 mW/sq.cm
for 10 seconds for a total of 20 seconds.
7 BRACES cycle (orthodontics):
Emission of 3300 mW/sq.cm for 3 seconds (5 emissions).
The BRACES cycle can be run a maximum of two times.
For safety reasons, after these two irradiation operations, an
extended pause of 30 seconds is required before the next
irradiation cycle can be started.
With this cycle, avoid direct irradiation of the gums and
mucous membranes or skin.
