User Manual
23
[Log alarm threshold (0-5000)]: When the remaining space reaches the set attendance records
threshold, time and attendance alarms users need clear records, the range is:0-5000.
[Precision]: There are three types of fingerprint quality: [Basic], [Good] and [Excellent], the
default for the [Good]; the higher accuracy of the fingerprint requirement is also higher.
[Intelligent update FP]: Update the fingerprint template with low score.
After setting press [Esc] key to save and return to the previous menu.
2.3.6.2 Application
In [Advanced] menu, select [Application] option and press [OK] key to enter [Application]
interface:
2.3.6.2.1 Access
In [Advanced] press [] key to select [Application] option, then select [Access] and press [OK]
key to enter [Access] interface to control the access:
[Relay output mode]: There are 4 modes.
1-door 2-door: means both two relays control the lock
1-door 2-ring: means relay1 controls the lock, relay2 controls ring
1-door 2-alarm: means relay1 controls the lock, relay2 controls tamper alarm
None: means disable both two relays
[Wiegand format]: There are four modes: Wiegand 26 mode, Anviz Wiegand, Fix Facility Code ,
and card module. Default is Wiegand 26.
[Tamper alarm]: Select ―Yes‖ tamper detection settings, select ―No‖ does not detect.
[Door sense switch]: Select ―Yes‖ Magnetic detection settings, select ―No‖ does not detect.
[Fix wiegand code(0-254)]: If the same fingerprint ID number uploaded to two different
machines, compared with the output of the Wiegand number after passing. If these two
machines set to the same area code, then the output of the Wiegand number will be the same.
[Lock delay time (0-15s)]: After the attendance, relay delay acting time, delay in the range 0-15
seconds.
After setting finished, press [Esc] key to save and return to the previous menu.
