MHPTV TX Quick Start Guide
MHPTV-QSG-DOC-V1.1, 12/05/2018 Page 36 of 37
13. You may network your Transmitter Control Module (rear LAN connector,
default IP address 192.168.1.210) and your Exciter (REMOTE RJ-45 rear panel
connection at 192.168.1.143), and your PA drawers (rear Lan port
192.168.1.200 – note – you will need to change some of the PA IP address (via
the PA built-in web interface) to avoid network conflicts if putting all PAs on
your network for remote monitor/control. All equipment IP addresses are user-
configurable via their respective user interfaces, so they may be configured to
match the TX sites specific IP addressing scheme.
If you desire to have remote monitoring and control, before leaving the station,
please be sure to set the Transmitter to REMOTE mode via the Controller
CONTROL button setting and set the Exciter to REMOTE mode under the
SYSTEM submenu by setting CTL=RMT. This will enable remote monitoring
and control of the TX via its built-in web interfaces (refer to the MHPTV TX
and Exciter user manuals for details).
Set Target AGC to
desired System
Forward Power, Turn
AGC ON/OFF
To Next Page
