AOC A2272PWHT User Manual

50
SPECIFICATIONS
LCD Panel
Driving system 21.5” WLED
Size 54.7cm diagonal
Pixel Pitch 0.24825mm(H) × 0.24825mm(V)
Input
Video
R, G, B Analog Interface
Digital
Separate Sync. H/V TTL
H-Frequency 30kHz ~ 83kHz
V-Frequency 50 ~ 76Hz
Display Colors 16.7M Colors
Dot Clock 170MHz
Max. Resolution 1920×1080@60Hz
Plug & Play VESA DDC2B™
LAN Speed 10/100Mbps
RF Module M/N WSDB-673GN
Power Consumption
ON Mode 30W (Typ.)
Standby Mode
≤
1.5W (VGA/HDMI),
≤
10W (Android)
OFF Mode
≤
0.5W
Input Connector
D-Sub 15pin
HDMI 19pin
Input Video Signal
Analog: 0.7Vp-p(standard), 75 OHM, positive or negative
HDMI: 0.7Vp-p(standard), 75 OHM, positive or negative
Power Source 100~240VAC, 50/60Hz
Environmental Considerations
Operating Temp.: 0° to 40°C
Storage Temp.: -20° to 60°C
Operating Humidity: 15% to 90%
Dimensions 561.93(W) x 355(H) x 47.1(D) mm
Weight (N. W.): 5.0 kg
Touch screen specifications
Touch technology Infrared Optical Structure
Input Method Finger, gloved hand, or any other opaque stylus
Touch stylus diameter
≥
7 mm
Resolution 32767 x 32767
Touch accuracy < ± 2.5 mm 95% coverage
Operating Systems
Microsoft Windows 8 Multi-Touch (2 points)
Microsoft Windows 7 Multi-Touch (2 points)
Microsoft Windows Vista Single Touch
Microsoft Windows XP Single Touch+Action
