Adjusting

Hotkeys

1 2 3 4 5

1 Source/Auto/Exit

2 Game Mode

3 Dial Point

4 Menu/Enter

5 Power

Menu/Enter

Press to display the OSD or conrm the selection.

Power

Press the Power button to turn on the monitor.

Dial Point

When there is no OSD, press Dial Point button to show / hide Dial Point.

Game Mode

When there is no OSD, press “ ” key to open game mode function, then press “ ” or “ ” key to select game mode (FPS,

RTS, Racing, Gamer 1, Gamer 2 or Gamer 3) basing on the different game types.

Source/Auto/Exit

When the OSD is closed, press Source/Auto/Exit button will be Source hot key function. When the OSD is closed, press

Source/Auto/Exit button continuously about 2 second to do auto congure (Only for the models with D-Sub).

Questions and Answers:

Need help?

Do you have a question about the AOC C32G2E and is the answer not in the manual?

AOC C32G2E Specifications

General

Panel type	VA
Pixel pitch	0.363 x 0.363 mm
Response time	0.5 ms
Backlight type	W-LED
Display surface	Matt
Display diagonal	32 \
Adobe RGB coverage	91 %
Native aspect ratio	16:9
Vertical scan range	48 - 240 Hz
Horizontal scan range	30 - 255 kHz
Viewable size, vertical	336.312 mm
sRGB coverage (typical)	120 %
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	597.888 mm
Display brightness (typical)	250 cd/m²
AMD FreeSync	Yes
Product color	Black, Red
Market positioning	Gaming
Sustainability certificates	ENERGY STAR
DVI port	-
DisplayPort version	1.2
Tilt angle range	3.5 - 21.5 °
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SER
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	31 W

Weight and Dimensions
