AOC CU32V3 User Manual

10
Adjusting
Hotkeys
4
2
1
3
5
1 Source/Exit/Up
2 Eco/DCR/Uniformity/Down
3 Clear Vision/Left
4 Volume/Right
5 Power/ Menu/Enter
Power/Menu/Enter
Press the Power button to turn on the monitor.
When there is no OSD, Press to display the OSD or conrm the selection. Press about 2 second to turn off the monitor.
Volume/Right
When there is no OSD, Press Volume button to active volume adjustment bar, Press Left or Right to adjust volume.
Source/Exit
When the OSD is closed, press Source/Exit button will be Source hot key function.
Eco /DCR/Uniformity/Down
When there is no OSD, Press this button to enter Eco/DCR/Uniformity adjustment. Then press Left or Right button to
choose different Eco/DCR/Uniformity.

AOC CU32V3 Specifications

General

3D	No
Panel type	VA
Color depth	8 bit
Pixel pitch	181.59 x 181.59 mm
Backlight type	W-LED
Display diagonal	31.5 \
Screen curvature	1500 mm
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Supported video modes	2160p
Screen curvature rating	1500R
Viewable size, vertical	392.234 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	-
Display number of colors	16.78 million colors
Display diagonal (metric)	80 cm
Viewable size, horizontal	697.306 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	3840 x 2160
Flicker-free technology	Yes
Feet color	Black/Silver
Certification	FCC
Product color	Black
Tilt angle range	-3.5 - 16.5 °
Number of OSD languages	16
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
DisplayPort version	1.2
VGA (D-Sub) ports quantity	0
Cables included	DisplayPort, HDMI
Power cable length	1.8 m
Sustainability certificates	RoHS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	41 W
Package type	Box
Package depth	224 mm
Package width	817 mm
Package height	640 mm
Package weight	9620 g

Weight and Dimensions

Depth (with stand)	205.8 mm
Width (with stand)	708.8 mm
Height (with stand)	524.6 mm
Weight (with stand)	7710 g
