AOC CU32V3 User Manual

13
Luminance
Luminance Color Setup Picture Boost OSD Setup ExitExtra
Contrast 50
Brightness 90
Eco mode Standard
Gamma Gamma 1
DCR Off
Overdrive Off
Contrast 0-100 Contrast from Digital-register.
Brightness 0-100 Backlight Adjustment
Eco mode
Standard Standard Mode
Text Text Mode
Internet Internet Mode
Game Game Mode
Movie Movie Mode
Sports Sports Mode
Reading Reading Mode
Uniformity Uniformity Mode
Gamma
Gamma1 Adjust to Gamma 1
Gamma2 Adjust to Gamma 2
Gamma3 Adjust to Gamma 3
DCR
Off Disable dynamic contrast ratio
On Enable dynamic contrast ratio
Overdrive
Weak
Adjust the response time.
Medium
Strong
Off

AOC CU32V3 Specifications

General

3D	No
Panel type	VA
Color depth	8 bit
Pixel pitch	181.59 x 181.59 mm
Backlight type	W-LED
Display diagonal	31.5 \
Screen curvature	1500 mm
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Supported video modes	2160p
Screen curvature rating	1500R
Viewable size, vertical	392.234 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	-
Display number of colors	16.78 million colors
Display diagonal (metric)	80 cm
Viewable size, horizontal	697.306 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	3840 x 2160
Flicker-free technology	Yes
Feet color	Black/Silver
Certification	FCC
Product color	Black
Tilt angle range	-3.5 - 16.5 °
Number of OSD languages	16
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
DisplayPort version	1.2
VGA (D-Sub) ports quantity	0
Cables included	DisplayPort, HDMI
Power cable length	1.8 m
Sustainability certificates	RoHS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	41 W
Package type	Box
Package depth	224 mm
Package width	817 mm
Package height	640 mm
Package weight	9620 g

Weight and Dimensions

Depth (with stand)	205.8 mm
Width (with stand)	708.8 mm
Height (with stand)	524.6 mm
Weight (with stand)	7710 g
