Extra

Picture Boost OSD SetupExit

Luminance

Color Setup

Off Timer 00

Input Select Auto

Auto Config. No

Reset No

Image Ratio Wide

DDC/CI Yes

Resolution : 1920(H)X1080(V)

H. Frequency : 67KHz

V. Frequency : 60Hz

Extra

Input Select Select Input Signal Source

Auto Cong. Yes or No

Auto adjust the picture to default. (Only for the

models with D-Sub)

Off timer 0-24hrs Select DC off time

Image Ratio Wide/4:3/1:1/Movie1/Movie2 Select image ratio for display.

DDC/CI Yes or No Turn ON/OFF DDC/CI Support

Reset Yes or No Reset the menu to default

Questions and Answers:

Need help?

Do you have a question about the AOC CU32V3 and is the answer not in the manual?

AOC CU32V3 Specifications

General

3D	No
Panel type	VA
Color depth	8 bit
Pixel pitch	181.59 x 181.59 mm
Backlight type	W-LED
Display diagonal	31.5 \
Screen curvature	1500 mm
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Supported video modes	2160p
Screen curvature rating	1500R
Viewable size, vertical	392.234 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	-
Display number of colors	16.78 million colors
Display diagonal (metric)	80 cm
Viewable size, horizontal	697.306 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	3840 x 2160
Flicker-free technology	Yes
Feet color	Black/Silver
Certification	FCC
Product color	Black
Tilt angle range	-3.5 - 16.5 °
Number of OSD languages	16
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
DisplayPort version	1.2
VGA (D-Sub) ports quantity	0
Cables included	DisplayPort, HDMI
Power cable length	1.8 m
Sustainability certificates	RoHS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	41 W
Package type	Box
Package depth	224 mm
Package width	817 mm
Package height	640 mm
Package weight	9620 g
