AOC CU34P2A User Manual

23
Specification
General Specification
Panel
Model name CU34P2A
Driving system TFT Color LCD
Viewable Image Size 86.36 cm diagonal
Pixel pitch
0.23175mm(H) x 0.23175mm(V)
Video HDMI lnterface & DP Interface
Display Color 16.7M Colors
Others
Horizontal scan range 30-160KHZ(HDMI/DP)
Horizontal scan Size(Maximum) 797.22mm
Vertical scan range
48-100HZ(HDMI/DP)
Vertical Scan Size(Maximum) 333.72mm
Optimal preset resolution 3440x1440@60Hz
Max resolution 3440x1440@100Hz(HDMI/DP)
Plug & Play VESA DDC2B/CI
Input Connector HDMI/DP
Power Source 100-240V~, 50/60Hz,1.5A
Power
Consumption
Typical (default
brightness and contrast)
55W
Max. (brightness = 100,
contrast =100)
115W
Standby mode ≤0.5W
Physical
Characteristics
Connector Type HDMI/DP/USB/Earphone out
Signal Cable Type Detachable
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0~ 5000m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )

AOC CU34P2A Specifications

General

Panel type	VA
Color depth	8 bit
Pixel pitch	0.2745 x 0.2745 mm
Backlight type	W-LED
Display surface	Matt
Display diagonal	34 \
Screen curvature	1500 mm
Surface hardness	3H
Anti-glare screen	Yes
Adobe RGB coverage	89 %
Display technology	LED
Native aspect ratio	21:9
Supported video modes	1080p, 1440p
NTSC coverage (typical)	85 %
Screen curvature rating	1500R
Viewable size, vertical	333.72 mm
sRGB coverage (typical)	120 %
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	86.36 cm
Viewable size, horizontal	797.22 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440, 3440 x 1440
Certification	True
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Tilt angle range	-5 - 23 °
Height adjustment	150 mm
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	55 W
Sustainability certificates	EPEAT Silver
RMS rated power	3 W
Compatibility	VESA-P2
Package type	Box
Package depth	250 mm
Package width	903 mm
Package height	527 mm
Package weight	12700 g
Cables included	AC, DisplayPort, HDMI
DisplayPort cable length	1.8 m
Exterior finish type	Textured
Recyclable packaging material	100 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	275.13 mm
Height (with stand)	611.53 mm
Weight (with stand)	9800 g
Depth (without stand)	100.14 mm
Width (without stand)	808.34 mm
Height (without stand)	367.45 mm
