AOC CU34P2A User Manual

2
Power
The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the
type of power supplied to your home, consult your dealer or local power company.
The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will t
only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an
electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the safety purpose of
the grounded plug.
Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will protect the
monitor from damage due to power surges.
Do not overload power strips and extension cords. Overloading can result in re or electric shock.
To ensure satisfactory operation, use the monitor only with UL listed computers which have appropriate congured
receptacles marked between 100-240V AC, Min. 5A.
The wall socket shall be installed near the equipment and shall be easily accessible.

AOC CU34P2A Specifications

General

Panel type	VA
Color depth	8 bit
Pixel pitch	0.2745 x 0.2745 mm
Backlight type	W-LED
Display surface	Matt
Display diagonal	34 \
Screen curvature	1500 mm
Surface hardness	3H
Anti-glare screen	Yes
Adobe RGB coverage	89 %
Display technology	LED
Native aspect ratio	21:9
Supported video modes	1080p, 1440p
NTSC coverage (typical)	85 %
Screen curvature rating	1500R
Viewable size, vertical	333.72 mm
sRGB coverage (typical)	120 %
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	86.36 cm
Viewable size, horizontal	797.22 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080), 2560 x 1440, 3440 x 1440
Certification	True
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Tilt angle range	-5 - 23 °
Height adjustment	150 mm
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	55 W
Sustainability certificates	EPEAT Silver
RMS rated power	3 W
Compatibility	VESA-P2
Package type	Box
Package depth	250 mm
Package width	903 mm
Package height	527 mm
Package weight	12700 g
Cables included	AC, DisplayPort, HDMI
DisplayPort cable length	1.8 m
Exterior finish type	Textured
Recyclable packaging material	100 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	275.13 mm
Height (with stand)	611.53 mm
Weight (with stand)	9800 g
Depth (without stand)	100.14 mm
Width (without stand)	808.34 mm
Height (without stand)	367.45 mm
