AOC CU34P2C User Manual

25
Specification
General Specification
Panel
Model name CU34P2C
Driving system TFT Color LCD
Viewable Image Size 86.36 cm diagonal
Pixel pitch 0.23175mm(H) x 0.23175mm(V)
Video HDMI lnterface & DP Interface
Display Colors 8 bit
Others
Horizontal scan range 30-160KHZ
Horizontal scan Size(Maximum) 797.22mm
Vertical scan range 48-100HZ
Vertical Scan Size(Maximum) 333.72mm
Optimal preset resolution 3440x1440@60Hz
Max resolution 3440x1440@100Hz(HDMI,DP,USB C*)
Plug & Play VESA DDC2B/CI
Input Connector HDMI/DP
Power Source 100-240V~, 50/60Hz,2A
Power
Consumption
Typical (default
brightness and contrast)
55W
Max. (brightness = 100,
contrast =100)
185W
Standby mode ≤0.5W
Physical
Characteristics
Connector Type HDMI/DP/USB/USB C
Signal Cable Type Detachable
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0~ 5000m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )
*Note: USB C(DP Alt) signal input, and “USB” is set to “2.0”, the maximum resolution is 3440x1440@100Hz
Color bits Limitation:
CU34P2C
422/420 444/RGB 422/420 444/RGB 422/420 444/RGB
(HDMI2.0) (HDMI2.0) (DP1.2) (DP1.2)
USBC@
USB3.2
USBC@
USB2.0
USBC@
USB3.2
USBC@
USB2.0
WQHD 100Hz 8 bit
NA OK OK OK NA OK NA OK
WQHD 75Hz 8 bit
NA OK OK OK OK OK NA OK
low resolutions 8 bit/10 bit
8 bit OK
10 bit NA
8 bit OK
10 bit NA
8 bit OK
10 bit NA
8 bit OK
10 bit NA
8 bit OK
10 bit NA
8 bit OK
10 bit NA
8 bit OK
10 bit NA
8 bit OK
10 bit NA
