AOC E2260SWD User Manual

48
E750 750GBT215W4C11N400 PANEL BM215WF4-TJC1
750GBT215W4C11N200 PANEL BM215WF4-TJC1 2nd source
750GBT215W4C11N300 PANEL BM215WF4-TJC1 2nd source
750GBT215W4C11N000 PANEL BM215WF4-TJC1 2nd source
2436L-2207D BM215WF4-TJC1-6F4
3110T-0856A
GALVALUME,
T=0.3,BM215WF4-TJA1-6F1-A0，Up
3110T-0856B
GALVALUME,
T=0.3,BM215WF4-TJA1-6F1-A0，Down
3850L-0088A ID, YUPO, 78X37
4296L-0284B
PMP-P2 100-520U-13, 5U-C60 black
A600, 170x7x0.45
6060L-2238B LM215WF4(TJC1,T2C2/T2C4)
6060L-3138B LM215WF4-T1H2-612 2nd source
6061L-1748B LM215WF4(TRH1,T2C2/T1H2,TJC1)
0ILUL-0203A
LS0609H3-C6LX, LUSEM, 960, 6BIT,
MINI, C_B, R/TP, 48MM, 4PF, UPILEX,
T9
6308L-3214A
LTXXNSSNEX5-02150B12, 487.1 X
277.5, LGC, T, X, X, N, S, S, N, E, X, 5,
02150, Bottom, 12
6308L-3215A
LTBXNSSNEX5-02150T12, 487.1 X
277.5, LGC, T, B, X, N, S, S, N, E, X, 5,
02150, Top, 12
6884L-0090A
CP12941-20YA, SONY,
1.5MMX300MM, 20UM
6884L-0053A
CP2420ISL,L=1.5MMX300M, T=18UM,
SONY
2nd source
6884L-0034A
CP5420ISL, SONY, L=1.5MMX300M,
T=20
2nd source
6871L-2552B
Source, Single, None-C/SKD,
LM215WF4-TJC1, Single Side
C115 0CH2103K562 10NF, K, 50V, X7R, 0.9mm, 1608, R/TP
C915,C916 0CH2104H942 0.1uF, Z, 25V, Y5V, 0.9mm, 1608, R/TP
C1,C2,C302,C5,C51,C6,
C7,C8,C924
0CH2104K562 0.1UF 50V K X7R 1608 R/TP
C79,C911 0CH2473H562 47nF, K, 25V, X7R, 0.9mm, 1608, R/TP
C56,C57,C74 0CH2473K562 47NF 50V K X7R 1608 R/TP
C3,C36,C4,C908 0CH2A-0007A
1U F, 10 Volt, K PER, X5R(JB), 1608
R/TP, T=0.9(MAX)
C50,C55,C58,C59 0CH2A-0010A 33nF, M, 25V, X7R, 0.9mm, 1608, R/TP

AOC E2260SWD Specifications

General

3D	No
Panel type	TN
Pixel pitch	248 x 248 mm
Aspect ratio	16:9
Backlight type	W-LED
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Maximum refresh rate	60 Hz
Viewable size, vertical	268.5 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	477.5 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Mean time between failures (MTBF)	50000 h
HDCP	Yes
DVI-I ports quantity	0
Tilt angle range	-5 - 15 °
Height adjustment	-
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	18 W
Certification	ISO 9241-307
Product color	Black
Sustainability certificates	TCO
Package weight	4080 g

Weight and Dimensions

Depth (without stand)	185 mm
Width (without stand)	511 mm
Height (without stand)	373 mm
Weight (without stand)	2600 g
