C22,C23,C32,C33,C34 0CH2A-0011A

10U F, 16 Volt, K PER, X5R(JB), 3216

R/TP, T=0.95(MAX)

C101,C102,C103,C104,C

105,C106,C107,C108,C1

09,C110,C111,C112,C11

3,C114,C301,C303,C305,

C307,C309,C311,C77,C9

0CH2A-0015A 1uF, K, 25V, X5R, 0.9mm, 1608, R/TP

C73 0CH2A-0017A

2.2U F, 10 Volt, K PER, X5R(JB), 1608

R/TP, T=0.9(MAX)

C313,C314,C315,C318,C

52,C61,C62,C63,C64,C71

,C72,C913,C914,C920,C9

0CH2A-0026A

10U F, 25 Volt, K PER, X5R(JB), 3225

R/TP, T=1.0(MAX)

C312 0CH2A-0038A

0.1U F, 25 Volt, Z PER, Y5V(JF), 1005

R/TP, T0.55(MAX)

C701 0CH2A-0049A 1.5nF, 50, -10~+10(K), 1608, X7R(JB)

C75 0CH2A-0088A 3.3nF, K, 50V, X7R, 0.9mm, 1608, R/TP

C912 0CH2A-0091A 1uF, K, 25V, X5R, 0.6mm, 1005, R/TP

D3,D4,D5 0DHZL-0008B BAV99-7-05-F, DIODES, SOT-23, R/TP

ZD1 0DHZL-0061A SDZ6V2D, AUK, SOD-323, R/TP

D6 0DHZL-0095A RB050M-30, ROHM, PMDU, R/TP

F1 0FFST-0002A

F0603FA2500V032T, AEM, 2.5, 32 Volt,

1.6X0.8X0.8, SMT, Ceramic, UL/CSA

U3 0IDIL-0002A

AP7167-FNG-7, DIODES,

ADJUST_3.3V, 1.2A, DFN3030-10,

R/TP, 10

UC2 0IIML-0004A

iML7821BE, IML, 5V~20V, 320mA,

20V/us, 40MHz, 1Ch, TSOT, R/TP, 5Pin

U4 0ISGL-0008C

M24C04-RDW, STmicroeletronics, 4K,

5ms, TSSOP, R/TP, 8

US2 0ISML-0007A

SM4025, SILICON MITUS, MONITOR,

BOOST+L/S(GPM)+OP-AMP+PVCOM+

DISCHARGING,

UC1 0ISWL-0078A

SW0640, SIW, LVDS, 6/8, 2,

MINI-LVDS, 6, 1, DRD, GIP, AFRC,

DGA, MUTE, MLF, TR, 68

L1 0LCAA-0069B

TNI8016-100M, DACOWELL, 10UH,

M=20%, 2.1A, 0.093, 8.0X11.0X1.8

(1.2MM, IN-BOARD), R/TP

FL4,FL5,R103,R109,R11 0RH0000C622 0 OHM 1/10W 0603 0.05R MAX
