AOC E2260SWD User Manual

51
R252 0RH6201C422 6.2K OHM 1/10W 0603 1%
R254 0RH6202C422 62K OHM 1/10W 0603 1%
R232 0RH7502C422 75K ohm, 1/16W, 1608, 1%, R/TP
R21,R231,R241,R251 0RH8201C422 8.2K OHM 1/10W 0603 1%
R221 0RH9101C422 9.1K OHM 1/10W 0603 1%
R910 0RH9102C422 91K OHM 1/10W 0603 1%
R224 0RHAA-0015A 43K ohm, 1/16W, 1608, 1%, R/TP
AR5,AR6 0RHZL10005A 100 OHM 1/10W 0603*4 5%
Q2 0TRRL-0010A
KTA1505S-Y-RTK/H, KEC, PNP, R/TP,
SOT-23, .
0TRRL-0019A
MMBT4403, Diodes, PNP, R/TP,
SOT-23, H/F, 3
2nd source
Q1 0TRRL-0011A
KTC3876S-Y-RTK/H, KEC, NPN, R/TP,
SOT-23, .
0TRRL-0020A
MMBT4401, Diodes, NPN, R/TP,
SOT-23, H/F, 3
2nd source
FL6,FL7,FL8,FL9 6200L-J015A BLM18PG300SN1D
RT1 6322L-0004A
22K ohm, +-3%, 125, 0.21, 3950, 1608,
R/TP
CN1 6630L-0157B
FI-XB30SL-HF10, JAE, 30 Pin, 1 mm,
Angle, Sn, USER LOCK
6630L-0410A
IS100-L30F-C15, UJU, 30 Pin, 1 mm,
Angle, Sn, USER LOCK
2nd source
6870S-1235A
LM215WF4-TJC1-611, 2L, 0.6,
479.15*122.15, 3, N, Source, NO, Single
Side
6884L-0078A
AC-9855RM, HITACHI, 2.0MM X 300M,
40UM
6884L-0061A CP20631-35YA, 2.0MMX300M, SONY 2nd source
6091L-1703C BM215WF4-TJC1
3022L-1413A
KOLON, XC210, T=0.123,
BM215WF4-TJA1-6F1-A0
3032L-1096A
KOLON,LE303, T=0.23, Angle = 4?，
BM215WF4-TJA1-6F1-A0
3034L-0937B
TORAY, T6D6, T=0.25, 3M, 1363-60,
BM215WF4-TJA1
3550B-0918A AL, T=0.5, BM215WF4-TJA1-6F1-A0
3850L-0092A BL, YUPO, 77X14
4975L-0464A BM215WF4-TJA1-6F1-A0
4974L-0864A
PC,ENTIRE,ETR-1010,V0,
BM215WF4-TJA1-6F1-A0
