AOC E2260SWD User Manual

52
5022L-0302A
SH140U+5256M, SILICON, Gray,
274.7*2.0*0.4
5022L-0303A
SH140U+5256M, SILICON, Gray,
485*2.0*0.4
5151L-0218B BM215WF4-TJA1
3953L-0144A
TORAY, 188E60L, T=0.188, 3M,
1363-60, 30.8*1.8*0.2,
BM200WD3-TJA1
3953L-0217A
TORAY, 188E60L, T=0.188, 3M,
1363-60, 441.7*1.8*0.2,
BM215WF4-TJA1-6F1-A0
3953L-0218A
TORAY, 188E60L, T=0.188, 3M,
1363-60, 286*1.8*0.2,
BM215WF4-TJA1-6F1-A0
5150L-0595A
PMMA, Flat, 2.0, Printing,
BM215WF4-TJA1-6F1-A0
6916L-0539C
EverTop, LED, 32(Number Of LED),
White LED, BM215WF4-TJA1
5153L-0068A 10FH-SM1-GAN-TB(LF)(SN) , JST
6915L-0284C
Ever Top LED,WM32NW1F,Top
View,2ea(LED Chip Q'TY per PKG),
7020PKG
6920L-0064A
283.4*4.2*1.2, 2ea(Number Of Chain),
1L(Number Of Layer), 32ea(Number Of
LED), AL
7250L-1401B TP-15;282.6*3.6*0.25T
7250L-0864A
NITTO, NITTO 5000NS, Clear,
30*3*0.16
7250L-1370A
Single Side Tape ** SYMBIO, KA180E,
Yellow, 12(W)*0.065(T), Insulating Tape
7250L-1408A ZH350 25x16x0.1
7250L-1488B
Conductive Tape,STN1026WR(P),
T=0.11, 15*25*0.11
756GFBCB0AA0980000 MCU ASS'Y
U402 056G2233-11
IC FLASH Pm25LD020C-SCE SIOC-8
2M PMC
056G2233501
IC FLASH MX25L2026DM1I-12G 2Mb
SOP-8 MXIC
2nd source
SMTCB-U402 100GAMJI000FT1 AOC E2260SWD
A33G1273AED-1L0100 CLIP
AM1G1740-10225-CR3 screw

AOC E2260SWD Specifications

General

3D	No
Panel type	TN
Pixel pitch	248 x 248 mm
Aspect ratio	16:9
Backlight type	W-LED
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Maximum refresh rate	60 Hz
Viewable size, vertical	268.5 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	477.5 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Mean time between failures (MTBF)	50000 h
HDCP	Yes
DVI-I ports quantity	0
Tilt angle range	-5 - 15 °
Height adjustment	-
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	18 W
Certification	ISO 9241-307
Product color	Black
Sustainability certificates	TCO
Package weight	4080 g

Weight and Dimensions

Depth (without stand)	185 mm
Width (without stand)	511 mm
Height (without stand)	373 mm
Weight (without stand)	2600 g
