AOC U2868PQU - Monitor Specifications; General Specifications

48
Specification
General Specification
Panel
Model name U2868PQU
Driving system TFT Color LCD
Viewable Image Size 708.538 mm diagonal(16:9)
Pixel pitch 0.16*RGB(H)mm x 0.16(V)mm
Video R, G, B Analog Interface
Separate Sync. H/V TTL
Display Color 16.7M Colors
Dot Clock 185.58 MHz
Resolution
Horizontal scan range 30a99.Hz9*$'9,+'0, a.+]'3
Horizontal scan
Size(Maximum)
62 mm
Vertical scan range Hz - Hz
Vertical scan Size(Maximum)  mm
Optimal preset resolution 3840×2160@60Hz
Plug & Play VESA DDC2B
Input Connector VGA/Dual link DVI/MHL/HDMI/DP/USB2.0/USB3.0
Input Video Signal Analog: 0.7Vp-p(standard), 75 OHM, Positive
Output Connector DP / earphone
Speaker 3 W x 2
Power Source 100-240V~ 50/60Hz 1.5A
Power Consumption
0 W(Max)
Standby ≦0.5 W (except HDMI/MHL mode)
Off timer 0-24 hrs
Physical
Characteristics
Connector Type VGA\ DVI\HDMI\DP in\DP out\ Line in\Earphone out\DC in
Signal Cable Type Detachable
Dimensions & Weight:
Height (with base) 560.6mm
Width 658.9 mm
Depth 245 mm
Weight (monitor only)
Wall Mount 100 x 100 mm
Environmental
Temperature:
Operating 0° to 40°C
Non-Operating -25° to 55°C
Humidity:
Operating 10% to 85% (non-condensing)
Non-Operating 5% to 93% (non-condensing)
Altitude:
Operating 0~ 3658m(0~ 12000 ft)
Non-Operating 0~ 12192m (0~ 40000 ft )
Since the MHL provides mobile phone charging function and share the same connector with HDMI, Whether the
8 kg
