Adjusting

Hotkeys

1 2 3 4 5

1 Source/Exit

2 Clear Vision/<

3 Volume/>

4 Menu/Enter

5 Power

Power

Press the power key to turn on/off the monitor.

Menu/Select

Activate the OSD menu or function adjustment conrmation.

Volume / increase

When the OSD menu is closed, press the “>” key to open the volume adjustment bar, and press the “<” or “>” key to

adjust the headphone output volume.

Source switching/exit

When the OSD menu is off, press this key to activate the signal source switching function, press this key continuously to

select the signal source displayed in the information bar, and press the menu key to adjust to the selected signal source.

When the OSD menu is active, this button acts as an exit key (to exit the OSD menu)

Questions and Answers:

Need help?

Do you have a question about the AOC U28P2U and is the answer not in the manual?

AOC U28P2U Specifications

General

Pixel pitch	0.16 x 0.16 mm
Screen shape	Flat
Display diagonal	28 \
Display technology	-
Vertical scan range	23 - 75 Hz
Horizontal scan range	30 - 140 kHz
NTSC coverage (typical)	107 %
Viewable size, vertical	341.28 mm
sRGB coverage (typical)	119 %
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	1000:1
Display number of colors	1.07 billion colors
Viewable size, horizontal	620.928 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3840 x 2160
HDMI	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	45 W
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Panel mounting interface	100 x 100 mm
Certification	CE, CB, FCC, BSMI, KC / KCC / eStandby
Product color	Black, Grey
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
