AOC U28P2U User Manual

17
PIP Setting
Picture Boost OSD Setup PIP Setting ExitExtra
PIP
Luminance
Size
Position
AudioSub Source DP
PIP Off Small Swap Off
Main Source
HDMI1
Off
Right-up
Color Setup
Game Setting
PIP
PIP Setting OFF / PIP / PBP Disable or Enable PIP or PBP.
Main Source
HDMI1 、HDMI2 、DP、
USB-C
Select main screen source.
Sub Source
HDMI1 、HDMI2 、DP、
USB-C
Select sub screen source.
Size Small / Middle / Large Select screen size.
Position
Right-up
Set the screen location.
Right-down
Left-up
Left-down
Audio
On: PIP Audio
Disable or Enable Audio Setup.
Off: Main Audio
Swap
On: Swap
Swap the screen source.
Off: non action

AOC U28P2U Specifications

General

Pixel pitch	0.16 x 0.16 mm
Screen shape	Flat
Display diagonal	28 \
Display technology	-
Vertical scan range	23 - 75 Hz
Horizontal scan range	30 - 140 kHz
NTSC coverage (typical)	107 %
Viewable size, vertical	341.28 mm
sRGB coverage (typical)	119 %
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	1000:1
Display number of colors	1.07 billion colors
Viewable size, horizontal	620.928 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3840 x 2160
HDMI	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	45 W
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Panel mounting interface	100 x 100 mm
Certification	CE, CB, FCC, BSMI, KC / KCC / eStandby
Product color	Black, Grey
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	200.1 mm
Height (with stand)	404 mm
Weight (with stand)	6760 g
Depth (without stand)	49.3 mm
Width (without stand)	636.42 mm
Height (without stand)	368.5 mm
Weight (without stand)	4770 g
