AOC U28P2U User Manual

6
Setup
Contents in Box
*
*
Monitor
CD Manual
Warranty Card Stand Base
Power Cable HDMI Cable USB CableDP Cable
*
*
*
Not all signal cables will be provided for all countries and regions. Please check with the local dealer or AOC branch
ofce for conrmation.

AOC U28P2U Specifications

General

Pixel pitch	0.16 x 0.16 mm
Screen shape	Flat
Display diagonal	28 \
Display technology	-
Vertical scan range	23 - 75 Hz
Horizontal scan range	30 - 140 kHz
NTSC coverage (typical)	107 %
Viewable size, vertical	341.28 mm
sRGB coverage (typical)	119 %
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	1000:1
Display number of colors	1.07 billion colors
Viewable size, horizontal	620.928 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3840 x 2160
HDMI	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	45 W
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Panel mounting interface	100 x 100 mm
Certification	CE, CB, FCC, BSMI, KC / KCC / eStandby
Product color	Black, Grey
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	200.1 mm
Height (with stand)	404 mm
Weight (with stand)	6760 g
Depth (without stand)	49.3 mm
Width (without stand)	636.42 mm
Height (without stand)	368.5 mm
Weight (without stand)	4770 g
