Picture Boost OSD SetupExit

Luminance

Color Setup

Off Timer 00

Input Select Auto

Reset No

Image Ratio Wide

DDC/CI Yes

Resolution : 3840(H)X2160(V)

H. Frequency : 135KHz

V. Frequency : 60Hz

Extra

Game Setting

PIP Setting

PIP

Input Select Select Input Signal Source

Off timer 0-24hrs Select DC off time

Image Ratio

Wide

Select image ratio for display.

4:3

1:1

Movie1

Movie2

DDC/CI yes or no Turn ON/OFF DDC/CI Support

Reset ENERGY STAR

or No

Reset the menu to default

(ENERGY STAR

available for selective models)

Questions and Answers:

Need help?

Do you have a question about the AOC U28P2U and is the answer not in the manual?

AOC U28P2U Specifications

General

Pixel pitch	0.16 x 0.16 mm
Screen shape	Flat
Display diagonal	28 \
Display technology	-
Vertical scan range	23 - 75 Hz
Horizontal scan range	30 - 140 kHz
NTSC coverage (typical)	107 %
Viewable size, vertical	341.28 mm
sRGB coverage (typical)	119 %
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	1000:1
Display number of colors	1.07 billion colors
Viewable size, horizontal	620.928 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3840 x 2160
HDMI	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	45 W
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Panel mounting interface	100 x 100 mm
Certification	CE, CB, FCC, BSMI, KC / KCC / eStandby
Product color	Black, Grey
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions
