1. Introduction
The Energy Communication Unit (ECU-R) is the information gateway for our inverters. The
unit collects module performance data from each individual inverter and transfers this
information to an Internet database in real time, requiring only a single data and power
cable. Through the Energy Monitoring and Analysis software, the ECU-R gives you precise
analysis of each inverter and module in your solar installation from APP. The user-friendly
interface lets you access your solar array in seconds.
Features
 Collects individual module and inverter statistics
 Communicates in real time
 Requires no additional wiring
The ECU-R is used in utility-interactive grid-tied
applications, and is made up of four key elements:
 Inverter
 Energy Communication Unit (ECU-R)
 APP (ECU APP)
Based on android and iOS.
 Energy Monitoring and Analysis (EMA)
Web-based monitoring and analysis system.
Figure 1
